TEST LABORATORY
Our test instrumentation is the following:
Vertical machine up to 600 kN, for tension tests (photo: tension test of yokes for 380 kV over-head lines)
Horizontal machine up to 300 kN, for tension and sliding tests, for span up to 12 mt. (photo: tension test of a copper conductor for TAV railway lines)
Equipment for determination of Brinnel hardness
Temperature and tension datalogger for internal calibrations
Transformer up to 8000 ampere, for magnetic losses tests and automatic heat cycle tests (photo: heat cycle test of compression clamps, joints and repair sleeves) Magnetoscope for material controls Equipment for determination of zinc thickness Calipers, gauges, comparators and micrometers J type thermocouples High tension ammeters Equipments for test of suspension clamps (photo: tension test of a suspension clamp) Electrodinamic shaker for vibrational analysis, with automatic control (photo: vibrational test of a vibration damper “Stockbridge” type) Automatic system for acquisition and analysis of temperature over raising and line drop in heat cycle tests and magnetic losses tests. Automatic system for acquisition and analysis of forces and accelerations in vibrational tests (photo: GORLA software for control of electrodinamic shaker)
Transformer up to 30 kV, for dielectrical tests (photo: dielectric test of a clamp for isolated conductor for Medium Voltage over-head lines)
Equipment for determination of slidings (photo: sliding tests of a “Stockbridge”, with the use of a displacement sensor) GORLA software for acquisition of displacements and forces in sliding tests (photo: software for acquisition of displacements and forces) Gorla software for execution and analysis of stress-strain tests (photo: image of a stress-strain curve and modulus of elasticity calculation)
